Cylindrical needle to plane electric field

Problem Type:
Axisymmetric problem of electrostatics.

Geometry:

cylindrical needle electrode
Distance from needle tip to plane surface - 5 mm.

Given:
Relative permittivity of air ε = 1;
Needle potential U = 10 kV
Plate potential 0 V

Problem:
Determine the electric field strength distribution as a function of needle diameter d.

Solution:
Parametric analysis is automated with LabelMover tool.

Results:
Electric potential distribution around the needle, d=2 mm.

needle-plane electric stress

Needle diameter d, mm.

2

6

10

22

Electric stress
at the needle tip, kV/mm.

9.7

4.6

3.5

2.6

View movie Download video.

Watch online on YouTube.

Download icon Download simulation files (files may be viewed using any QuickField Edition).

There are no restrictions applied to the QuickField Student Edition postprocessors.
You can view field maps, make plots, calculate integrals and print pictures in the same way that the Professional Edition users do.
